Rotors
- Highly efficient patented KyphoTM rotor profile.
- Precision milled to exact tolerances.
- Long-life cylindrical and tapered roller bearings ensure reliable, consistent operation.
- Extended bearing life due to vibration-free performance.
Oil Separator
- EliminatorTM air/oil separator has two times the surface area of conventional separators for improved separation and longer life.
- Low carry-over; less than two parts per million, measured before the aftercooler at 100 psig, full load operation.
Maintenance
- Simplified access to air/oil separator requiring no piping removal to change separator elements. Reduces maintenance time by 90%.
- Easy access to the full-flow, ten micron oil filter. Reduces time to complete periodic oil filter changes.
- Simple, patented system for adjusting belt drives.
Acoustic Enclosures
- Low overall noise level; Quiet enclosure option reduces sound to 76dBA.
- Unrestricted access to airend and motor provided by lift-off panel.
Control Piping
- Safe, corrosive-free compressor operation is a direct benefit from stainless steel control lines, a standard Gardner Denver feature.
- No plastic tubing, rubber hoses or black piping.
Mounted Aftercooler
- Factory mounted, heavy duty, air-cooled aftercooler and moisture separator with trap effectively reduces discharge air temperature to within 15°F of ambient.
Auto Sentry® RS-2000 (ES40/ES-50)
- Complete electronic control with complete self-diagnostic, protective shutdown, service advisory and full text digital display capabilities.
- Built-in selectable automatic re-start and sequencing (up to 8 units).
- Built-in self-diagnostic capability.
